TGR1900
OnHub Router
- The Google Wifi app guides you through setup, shows you which devices are connected to your network, and offers help if there's a Wi-Fi slow-down.*
- Searches every five minutes for the least crowded Wi-Fi channel and will switch if it improves your performance.
- 13 high-powered antennas arranged in an innovative circular design provide reliable Wi-Fi coverage* in more directions in your home.
- Prioritizes your favorite device to send more bandwidth where it matters most.
- Updates itself with the latest features and security upgrades as soon as they’re available.
What is OnHub?
Meet OnHub, a router for the new way to Wi-Fi. We’re streaming and sharing in new ways our old routers were never built to handle. OnHub is built for all the ways you Wi-Fi. OnHub provides fast Wi-Fi for all of your devices, speaks in a language you understand, and keeps getting better.
Explore more on Official Google Blog
Constantly works to improve your Wi-Fi.
A dedicated antenna and radio scans the environment every five minutes, and OnHub switches to a less crowded channel if it will improve your Wi-Fi performance. OnHub makes the switch when you’re not using the Internet so it doesn’t interrupt what you’re doing.
Innovative antenna design.
Provides reliable Wi-Fi coverage to more areas of your home with 13 powerful Wi-Fi antennas arranged in a circular pattern. Each antenna is paired with a perpendicularly oriented partner antenna so OnHub can select the polarization delivering the strongest signal for each device in your home. OnHub also features a front-facing antenna reflector that acts like a satellite dish enhancing Wi-Fi range in that direction.
Once you have your OnHub, download the free Google Wifi App to help you set up and manage OnHub right from your phone or tablet. Prioritize bandwidth to a device or troubleshoot issues, at home or away.
Speaks your language.
The companion Google Wifi App makes setup quick, and if there’s ever an issue with your Wi-Fi, it offers simple solutions to help. Plus it provides tools to help you monitor and manage your connection. Run a speed test, change your settings, see what devices are connected to your network, troubleshoot at home or away, and enable a friend to help you remotely.
The Google Wifi App is available for Android 4.0 or higher and iOS 7 or higher.
Keeps getting better.
OnHub is designed to last, even as the way we use Wi-Fi changes. Its hardware supports a growing number of smart devices, and automatic updates mean you’ll always have the latest features and security upgrades.
| HARDWARE FEATURES | |
|---|---|
| Interface | 1 10/100/1000Mbps LAN Port 1 10/100/1000Mbps WAN Port 1 USB 3.0 Port |
| Button | Reset Button |
| External Power Supply | 12V/3A |
| Dimensions ( W x D x H ) | 7.5in x 4.1in x 4.6in (190.5 x104 x117mm) |
| Antenna | 13 high-performance Wi-Fi antennas 1 bluetooth antenna 1 zigbee antenna |
| Others | Built-in speaker Congestion sensing Wi-Fi radio |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11ac/n/a 5GHz Wi-Fi IEEE 802.11b/g/n 2.4GHz Wi-Fi Bluetooth® Smart Ready 802.15.4 ready Google Weave ready |
| Frequency | 2.4GHz and 5GHz Band1/2/3/4 Wi-Fi 2.4GHz Bluetooth 2.4GHz Zigbee |
| Signal Rate | Wi-Fi 5GHz: Up to 1300Mbps 2.4GHz: Up to 600Mbps Bluetooth 4.0&HS |
| Reception Sensitivity | 5GHz: 11a 6Mbps: -92dBm 11a 54Mbps: -75dBm 11ac HT20: -74dBm 11ac HT40: -71dBm 11ac HT80: -81dBm 2.4GHz 11g 54M: -77dBm 11n HT20: -74dBm 11n HT40: -71dBm |
| Transmit Power | FCC: <30dBm |
| Transmission Power | FCC: <30dBm |
| OTHERS | |
|---|---|
| Certification | FCC, IC |
| Package Contents | OnHub Power supply unit 2 Ethernet Cables |
| System Requirements | For initial setup, the Google Wifi mobile app on a device with: - Android 4.0 or higher - iOS 7 or higher |
| Certifications | FCC, IC |
| Environment | Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
*Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range and coverage specifications along with the number of connected devices were defined according to test results under normal usage conditions. Actual wireless transmission rate, wireless coverage, and number of connected devices are not guaranteed, and will vary as a result of 1) environmental factors, including building materials, physical objects and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead and 3) client limitations, including rated performance, location, connection quality, and client condition.
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
