AV1300 3-Port Gigabit Passthrough Powerline Starter Kit
- HomePlug AV2 standard compliant - high-speed data transfer rates of up to 1300 Mbps, supports all your online needs‡
- 2×2 MIMO with Beamforming - ensures larger range, higher transmission capacity and more stable connections
- 3 × Gigabit Ports - Provide secure wired networks for desktops, smart TVs or games consoles
- Extra Power Socket - Get power from the outlet for your other devices with the integrated power socket
- Plug and Play - Set up your powerline network and start enjoying fast, seamless wired connections in minutes
- Patented Power-Saving Mode - automatically reduces power consumption by up to 85%*
AV1300 Powerline Kit
Bring Your Network Into New Era
HomePlug AV2
AV1300 3-Port
Gigabit Passthrough
Powerline Starter Kit
TL-PA8033P KIT
Upgraded 1300Mbps!
Perfect for Bandwidth
Demanding Activities
Advanced HomePlug AV2 technology means the TL-PA8033P KIT supports 2x2 MIMO with
beamforming, so users benefit from ultra-fast data transfer speeds of up to 1300Mbps.‡ Perfect for
bandwidth demanding activities like streaming Ultra HD video to multiple devices simultaneously,
online gaming and large file transfers.
Note: The MIMO functionality within HomePlug AV2 significantly improves
data transfer rates especially during peak periods.
Line-Neutral/Line-Ground
with Beamforming
Larger Range
MIMO Technology with Beamforming maximizes the performance on the independent streams, which improves coverage throughout the home, particularly for previously hard to reach outlets.
Long Distance Long Distance
MIMO SISO
Higher Transmission Capacity & More Stable Connections
MIMO Technology means the TL-PA8033P KIT can use the 3 wires, including the live, neutral and earth to create multiple data paths, meaning that you benefit from faster data throughput and more stable connections.
- Neutral Wire
- Line Wire
- Ground Wire
MIMO SISO
Note: MIMO - Multi-input Multi-output SISO - Single-input Single-output
3 Gigabit Ports
for Maximum Connectivity
With 3 gigabit Ethernet ports, TL-PA8033P KIT can simultaneously connect up to 3 wired-only devices. This makes the TL-PA8033P KIT the perfect home entertainment companion. Connect any 3 devices from smart TVs and game consoles to NAS boxes and computers to the Internet at the same time. Just plug the Ethernet cable into the powerline and away you go!
- Game Console
- 4K TV
- Computer
Plug and Play,
No Configuration Required
Connect a powerline adapter to the router; plug another powerline adapter into a wall socket in another room, and connect it to your Internet enabled device via Ethernet - and you’re done!
Note: Powerline adapters must be deployed in sets of two or more and be connected to the same electrical circuit.
Pair for more security
Get more security for your network with the simple paring process
Extra Power Socket for Additional Devices
The integrated power socket, with power output of up to 16A, means the powerline can be used like a traditional electrical socket. Simply plug in your device or extension lead as though it were a normal wall socket. The built-in noise filter also helps to prevent electrical signal noise from affecting Powerline performance.
Note: Power output of up to 16A is suitable for high-power
electrical appliances to be connected.
Power Save by
Up to 85%
TL-PA8033P KIT is a new-generation of Powerline adapter. Its sophisticated Power-Saving mode automatically switches from its regular “Working” mode to “Power-Saving” mode reducing energy consumption by up to 85%.*
- Working mode
- Power-Saving mode
| HARDWARE FEATURES | |
|---|---|
| Standards and Protocols | HomePlug AV2, HomePlug AV, IEEE 1901, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Plug Type | AU |
| Interface | TL-PA8030P: 3 * Gigabit Ethernet Port, Power SocketTL-PA8010P: 1 * Gigabit Ethernet Port, Power Socket |
| Button | Pair Button |
| Power Consumption | Maximum: 5.53WTypical: 5.32WStandby: 1.36W |
| LED Indicator | Power, Powerline, Ethernet |
| Dimensions ( W x D x H ) | 5.2×2.8×1.7 in. (131×72×42 mm) |
| Range | 300 Meters over electrical circuit |
| Power Output to Integrated Socket | 10A |
| SOFTWARE FEATURES | |
|---|---|
| Modulation Technology | OFDM (PLC) |
| Encryption | Powerline Security:128-bit AES |
| OTHERS | |
|---|---|
| Certification | CE, RoHS |
| Package Contents | Powerline Adapter TL-PA8010P, TL-PA8030P 2 × 6.5 ft. (2 m) Ethernet Cable Quick Installation Guide |
| System Requirements | Windows 2000/XP/2003/Vista, Windows 7/8, Mac, Linux |
| Environment | Operating Temperature: 0°C~40°C (32°F ~104°F)Storage Temperature: -40°C~70°C (-40°F ~158°F)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing |
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage per ft2 are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.
‡Maximum Powerline signal rates are the physical rates derived from G.hn specifications. Actual Powerline data throughput and Powerline range are not guaranteed and will vary as a result of network conditions and environmental factors, including electrical interference, volume of traffic and network overhead, AFCI circuit breaker, and Powerline being located in a separate circuit.
*The Power Saving feature takes effect when your appliances are disconnected or turned off. Actual power saving data will vary in different network conditions and environments.
Compatible with all HomePlug AV and AV2 Standard Powerline adapters. This product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or are non-standard or outdated.
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
