XZ000-G7
NuevoGPON SFU + 1x 1G LAN
- Conectividad: 1 SC/APC PON Port + 1 puertos Gigabit LAN Ethernet.
- Compatibilidad VLAN: 802.1Q TAG VLAN, VLAN Transparent/VLAN Translation/VLAN Trunk.
- Autenticación: Basada en Serial Number o Password.
- Gestión Remota: OMCI.
- ITU-T G.984/G.988 GPON: Compatible con los estándares de la Industria. Compatibilidad con gestión OMCI. Compatible con OLTs de Terceros.
1-Port
Gigabit XPON Terminal
XZ000-G7
High-Speed GPON Service
Compliant with the ITU-T G.984 GPON standards, XZ000-G7 supports maximum data rates of up
to 2.488 Gbps downstream, 1.244 Gbps upstream.*
Make
Fiber-to-the-Home Yours
TP-Link’s XZ000-G7 is a GPON (Gigabit Passive Optical
Network) + EPON (Ethernet Passive Optical Network) combo terminal,
ideal for Fiber-to-the-Home solution.
Gigabit Internet Access
One PON port and one Gigabit Ethernet port, XZ000-G7
provides high-performance forwarding capabilities to ensure
smooth VoIP, HD video streaming experiences.
PON
RESET
LAN
POWER
Ease of Use
Quick and hassle-free installation
| CARACTERÍSTICAS DE HARDWARE | |
|---|---|
| Interfaz | 1 PON Port1 10/100/1000 Mbps RJ45 Port |
| Botones | 1 RESET Button |
| Fuente de Alimentación Externa | 9VDC/0.6A |
| Estándares Inalámbricos | IEEE 802.3, 802.3u, 802.1p, 802.1Q |
| Tasa de Transferencia | Downstream Speeds: 2.488 Gbps (GPON), 1.25 Gbps (EPON)*Upstream Speeds: 1.244 Gbps (GPON), 1.25 Gbps (EPON)* |
| Longitud de Onda | Upstream: 1310 nmDownstream: 1490 nm |
| Dimensiones | 3.7 x 3.0 x 1.2 in. (95.0 x 75.0 x 29.3 mm) |
| Distancia | 0–20 Km Max |
| Estándares GPON | ITU-T G.988, G.984.1, G.984.2, G.984.3, G.984.4 |
| Módulo Óptico | Class B+ |
| Receptor | Super-TIA |
| Transmisor | DFB Laser |
| CARACTERÍSTICAS DE SOFTWARE | |
|---|---|
| Características Avanzadas | Upstream and Downstream FEC, Dynamic Bandwidth Allocation(DBA) support NSR/SR, Up to 16 T-CONTs and 256 GEM Ports, Optical power detection, Dying Gasp, Terminal Silent mechanism |
| VLAN | 802.1Q tag VLAN, VLAN transparent mode/VLAN translation mode/VLAN trunk mode, Authentication based on SN and Password, VLAN Auto Detect |
| Seguridad | AES Encryption, Packet Filter based on VLAN |
| Gestión | Local management: WebGUI, TelnetRemote management: OMCI |
| IGMP | IGMP v1/v2/v3 |
| Otros | |
|---|---|
| Contenido del Paquete | XZ000-G7Power Adapter |
| Requisitos | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or LinuxInternet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browserSubscription with an internet service provider (for internet access) |
| Certificaciones | CE, RoHS |
| Factores Ambientales | Operating Temperature: 0℃–40℃ (32℉–104℉)Storage Temperature: -40℃–60℃ (-40℉–140℉)Operating Humidity: 10%–90% non-condensingStorage Humidity: 5%–90% non-condensing |
*Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
