Archer D50
ProchainementModem Routeur ADSL2+ Wi-Fi bi-bande AC1200
- Prend en charge la norme 802.11ac, la prochaine génération de Wi-Fi
- Les bandes simultanées 2,4 GHz et 5 GHz offrent une expérience Wi-Fi haute qualité avec des débits allant jusqu'à 300 Mbps et 867 Mbps
- Partager une imprimante localement et des fichiers et des médias avec des appareils en réseau ou à distance via un serveur FTP
- Le port Ethernet WAN (EWAN) accepte les connexions des modems câble et fibre
- La nouvelle application Web UI and Tether permet une installation rapide, ainsi qu'une gestion simplifiée
Wireless Dual Band
ADSL2+ Modem Router
Superfast Wireless Speed with the 802.11ac Standard
Next generation AC Wi-Fi is three times faster than the wireless N standard. The Archer D50 delivers combined wireless data transfer speeds of up to 1200 Mbps, including 867 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band. With its increased efficiency and robust security, the 802.11ac standard offers a dramatically accelerated multimedia experience and easily serves multiple devices at the same time.
Premium Wireless Experience
Simultaneous dual band Wi-Fi offers increased flexibility by creating two dedicated networks that can support all of your basic online tasks and bandwidth-intensive applications. The two dual band external antennas expand the router’s range and enhance its performance.
Easy USB Storage
and Sharing
The Archer D50's multi-functional USB 2.0 port allows you to share a printer with multiple computers and devices on your local network. It also lets you share files and media at home or from anywhere in the world via FTP.
Dual Connectivity
The Archer D50 supports ADSL and Ethernet WAN inputs, providing you with the flexibility you need to get the most from your Internet connection. The ADSL port supports ADSL connections via any standard phone cable and the LAN/WAN port allows the Archer D50 to accept connections from fiber/cable modems using an Ethernet cable.
-
Guest Network
Provide a separate, secure Wi-Fi network for guests to share your home or office network
-
Parental Control
Establish appropriate access policies for children and staff members
-
Easy of Use
Enjoy the optimized configuration utility and the intelligent auto-detection function, which automatically identifies your connection type to get you online in a flash
-
IPv6 Supported
Future-proof your network with the next generation Internet protocol
Easy Setup and Use
Set up the Archer D50 in minutes thanks to its intuitive web interface and the powerful Tether App. Tether also lets you manage its network settings from any Android or iOS device, including parental controls and media sharing.
TP-LINK | Wireless ADSL2+ Modem Routers
| Products |
AC1900 Wireless Dual Band Gigabit ADSL2+ Modem Router |
AC1750 Wireless Dual Band Gigabit ADSL2+ Modem Router |
AC1200 Wireless Dual Band Gigabit ADSL2+ Modem Router |
AC1200 Wireless Dual Band ADSL2+ Modem Router |
| Standards | IEEE 802.11ac/n/g/b/a | IEEE 802.11ac/n/g/b/a | IEEE 802.11ac/n/g/b/a | IEEE 802.11ac/n/g/b/a |
|
Wireless Speed |
1300Mbps |
1300Mbps |
867Mbps |
867Mbps |
| Wireless Range | ||||
| EWAN | √ | √ | √ | √ |
| Gigabit Ports | √ | √ | √ | - |
| USB 2.0 Ports | 1 | 2 | 2 | 1 |
| USB 3.0 Ports | 1 | - | - | - |
| CARACTERISTIQUES MATERIELLES | |
|---|---|
| Interface | 1 10/100Mbps RJ45 WAN/LAN Port 3 10/100Mbps RJ45 LAN Ports 1 RJ11 Port 1 USB 2.0 Ports |
| Bouton | 1 Power On/Off Button 1 Wi-Fi On/Off Button 1 WPS Button 1 RESET Button |
| Alimentation | 12VDC/1.5A |
| Standards IEEE | IEEE 802.3, 802.3u, 802.3ab |
| Standards ADSL | Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs), ITU-T G.995.1 |
| Standards ADSL2 | ITU-T G.992.3 (G.DMT.bis), ITU-T G.992.4 (G.lite.bis) |
| Standards ADSL2+ | ITU-T G.992.5 |
| Dimensions (LxPxH) | 8.0 x 5.6 x 1.3 in. (202mm x 141mm x 33.6mm) |
| Antennes | Undetachable dual band external antennas |
| Gain de l'antenne | 2dBi for 2.4GHz and 3dBi for 5GHz |
| Caractéristiques WiFi | |
|---|---|
| Standards WiFi | IEEE 802.11ac/n/a 5GHz IEEE 802.11n/g/b 2.4GHz |
| Débit WiFi | 5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps |
| Fréquence WiFi | 2.4GHz and 5GHz |
| Fonctions WiFi | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Sécurité WiFi | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption, Wireless MAC Filtering |
| Puissance de transmission | <20dBm(EIRP) |
| Planification WiFi | Support 2.4GHz and 5GHz Wireless Schedule |
| CARACTERISTIQUES LOGICIELLES | |
|---|---|
| Qualité de Service QoS | ATM QoS, Bandwidth Control |
| Caractéristiques avancées | Parental Control Network Address Translation (NAT); Port Mapping (Grouping), Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS, IGMP V1/V2/V3 |
| Sécurité | NAT Firewall, Access Control, MAC / IP / URL Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death IP and MAC Address Binding |
| IPv6 | IPv6 and IPv4 dual stack |
| Modes opératoires | ADSL Modem Router, Wireless Router |
| Administration | Web Based Configuration(HTTP), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools |
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP relay |
| Redirection de port | Virtual server, Port Triggering, DMZ, ALG, UPnP |
| DNS dynamique | DynDns, NO-IP |
| VPN | PPTP, L2TP, IPSec Passthrough |
| Caractéristiques ATM | ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), Bridge (RFC1483 Bridge) PVC – Up to 8 PVCs |
| Partage USB | Support Samba(Storage)/FTP Server/Media Server/ Printer Server |
| Réseau invité | 2.4GHz guest network × 1 5GHz guest network × 1 |
| VPN IPsec | Supports up to 10 IPSec VPN tunnels |
| Autres | |
|---|---|
| Certification | CE, FCC, RoHS |
| Contenu de l'emballage | AC1200 Wireless Dual Band ADSL2+ Modem Router External Splitter RJ-11 Telephone Cable RJ-45 Ethernet Cable Quick Installation Guide Power Adapter |
| Système requis | Windows 10/8/7/Vista/XP or Mac OS or Linux-based operating system |
| Environnement | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
