TD25
ProchainementCaméra de sonnette vidéo Tapo
- Batterie de 8 mois ou filaire : batterie de 10 000 mAh ou câblée 8-24 V, prend en charge le pré-roulement lorsqu'elle est câblée.
- Clarté 2K 5MP : offre des détails plus fins et une clarté incroyable.
- Vue ultra-large à 180° : capture tout, de la tête aux pieds.
- Vision nocturne en couleur avec projecteur : visibilité nocturne et sécurité éclatantes.
- Détection et notification gratuites : alertes pour personne, véhicule, animal et colis.
- Audio bidirectionnel : conversation de haute qualité avec micro et haut-parleurs haut de gamme.
- Réponse rapide : Réaction rapide à toute situation.
- IP66 résistante aux intempéries : fiable dans toutes les conditions météorologiques.
- Stockage local et Cloud : prend en charge la carte microSD (jusqu'à 512 Go) et les services cloud Tapo Care.
Smart.Secure.Easy.
Always Know Who’s There
Video Doorbell Camera
TD25
-
Hardwire & Battery
Power Supply -
Chime
Included -
IP66 Water &
Dust Resistance
Live View + Starlight Sensor
4:3 /180° filed of View
Hardwire Supported
Person / Pet / Vehicle / Package
2K 5MP Head-to-Toe 180° DFOV
Details matter, and with 2K 5MP clarity, TD25 exceeds traditional Full HD resolution with finer details and incredible clarity. Experience the full picture with our 180° ultra-wide field of view, capturing every detail from head to toe in a single sweeping glance.
160°
Others brand
180°
TD25
Various Power Supply Methods
Flexible Wedges, Flexible Views
Different wedge choices give users possibilities to make the doorbell suits more placement scenarios. Users can also use these wedges to adjust the views.
Local and Cloud Storage
Save recorded videos on the microSD Card (up to 512 GB, purchased separately) or use Tapo Care cloud storage services (subscribe separately).
Up to
512 GB
Smart AI Detection and Notification
Smart AI identifies people, pets, vehicles, and packages, notifying users as needed.
Install Your Doorbell
Step 1
Option 1: Stick to the wall
Attach the included adhesive to the back of the bracket or the wedge you have selected. If you use the wedge, affix the bracket and the wedge with screws.
3M Adhesive
or
Mounting Wedge
Route the wires through the bracket (if there are existing wires) . Wipe off the dust from the surface using a dry cloth, stick the bracket with adhesive to the smooth wall, and press it down for 15 seconds to ensure the bracket is firmly attached.
or
Option 2: Mount to the wall
Route the wires (if there are existing wires) through the mounting template and stick the template. Drill two holes where indicated.
Φ=6 mm (15/64 in.)
Route the wires (if there are existing wires) through the bracket. Insert two anchors into the holes and use the screws to affix the bracket over the anchors.
Step 2 Mount the doorbell to the bracket
Option 1: Battery Powered
Mount the doorbell to the bracket.
Option 2: Hardwire Powered
Connect the wires to the doorbell and tighten the screws. Mount the doorbell to the bracket and turn on the circuit breaker.
If the wires are too short
| Caméra | |
|---|---|
| Capteur d'image | 1/2.7“ Progressive Scan CMOS Sensor |
| Optique | Focal Length: 1.18mmAperture: F1.8Field of View: 170.6° (Horizontal), 140.1° (Vertical) |
| Vision Nocturne | 850 nm IR LED (33 ft / 10 m)Full-Color Night Vision |
| Eclairage | Built-in Spotlights |
| Interface & Bouton | 1× RESET /SYNC Button1× Doorbell Button1× Anti-Theft Button1× Power ON/OFF Button |
| VIDEO & AUDIO | |
|---|---|
| Résolution Maximale | 2K 5MP (2560 × 1920px) |
| Fréquence d'images | 15/20 fps |
| Zoom Numérique | 16x |
| Compression vidéo | H.264 |
| Vue en direct | Yes |
| Amélioration de l'image | 3DNRWDR |
| Entrée et sortie audio | Built-in Microphone and Speaker |
| Audio Communication | Two-Way Audio with Noise Cancellation |
| Volume de la sirène | 98dB (Level measured at 4-inch/10-cm distance) |
| STOCKAGE | |
|---|---|
| Stockage Local | MicroSD Card Slot on Hub (Up to 512 GB) |
| Stockage Cloud | Tapo Care Cloud Storage Services (Subscription required) |
| DETECTION et NOTIFICATIONS | |
|---|---|
| Capteur | Single PIR Motion Sensor (FOV: 130° horizontal)One Ambient Light Sensor |
| Détection AI | Motion DetectionPerson DetectionPet DetectionVehicle DetectionPackage Detection |
| Zones d'activité | Yes*Only works with Motion Detection. |
| Notification de sortie | System NotificationSystem Notification with Snapshot (Tapo Care Services) |
| RESEAU | |
|---|---|
| Connectivité Réseau | IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
| Sécurité | |
|---|---|
| Sécurité | On-Device Machine Learning128-bit AES Encryption with SSL/TLSWPA/WPA2-PSK |
| ALIMENTATION | |
|---|---|
| Source d'alimentation | 10000 mAh Built-in Rechargeable Lithium-ion BatteryHardwire chargeHardwire supply |
| Tension d'entrée | Doorbell Battery Pack Adapter Input: 100-240 V, 50/60 Hz |
| Tension de sortie | Doorbell Battery Pack Adapter Output: 5.0 V, 2.0 A |
| Général | |
|---|---|
| Smart Integration | Google Assistant, Amazon Alexa |
| Weather Resistance | IP66 |
| System Requirements | Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher |
| Mounting Options | Stick to a WallMount to a Wall |
| Température de fonctionnement | -20℃~45℃ |
| Storage Temperature | -20℃~45℃ |
| Humidité de fonctionnement | 10%~90% RH, Non-condensing |
| Humidité de stockage | 0~90% RH, Non-condensing |
| Charging Temperature | 0-45℃ |
| Dimensions | Doorbell Dimensions: 2.13 × 1.97 × 1.52 in (150 × 50 × 38.4 mm)Chime Dimensions:US/JP Version: 2.87×1.85×1.71 in (73×46.9×43.5 mm)EU Version: 2.87 × 2.15 × 1.89 in (73×54.6×48 mm)UK Version: 2.87×2.45×1.71 in (73×62.3×43.5 mm)KR Version: 2.87×2.46×1.71 in (73×62.4×43.5mm)AU Version: 2.87×2.01×1.71 in (73×51×43.5 mm) |
| Contenu de la boite | Tapo Video Doorbell × 1Tapo Chime × 1Mounting Template × 1Mounting Bracket × 1Vertical Mounting Wedge× 1Horizontal Mounting Wedge × 1USB Adapter Cable × 1Jumper for Existing Chime × 1Extension Wires × 2Mounting Screws and Anchors × 3Hardwire Installation Screws × 2Doorbell Detaching Pin × 1Mounting Wedge Screws × 53M Adhesive × 1Foam Pad × 1Wire Nuts × 2Quick Start Guide |
| Certifications | CE, RoHS, RCM,R-NZ,FCC, EAC, Triman, UKCA |
