VIGI 2MP IR Dome Network Camera
- 2MP Full-High Definition and IR Night Vision
- Human & Vehicle Classification
- Smart Detection
- Smart Video Enhancement Technology
- Built-In Microphone
- IP67 Waterproof and IK10 Vandal-Proof
- H.265+ Compression Technology
Security Never Shuts Down
2MP IR Dome Network Camera
VIGI C220I
Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.
Learn more about VIGI AI technology >>
- Human & Vehicle Classification
- Only Human Classification On
- Only Vehicle Classification On
Alarm Triggered
Alarm Filtered
Alarm Triggered
Alarm Filtered
Alarm Triggered
Alarm Filtered
Smart Video Enhancement Technology
-
DWDR: Enhances video quality by improving dynamic range and detail presentation, making it perform excellently in diverse lighting conditions.
-
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
-
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
-
White Balance: White Balance ensures neutral whites in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.*
| CÁMARA | |
|---|---|
| Sensor de Imagen | 1/3” Progressive Scan CMOS |
| Velocidad del obturador | 1/3 to 1/10000 s |
| Obturador lento | Yes |
| Apertura | 2.8 mm: F2.24 mm: F2.0 |
| Lente | 2.8 mm/ 4 mm |
| Montura del lente | M12 |
| Iluminación mínima | Color: 0.01 Lux; 0 Lux with IR |
| Mecanismo día/noche | IR Cut Filter |
| Switch día/noche | Unified/ Scheduled/ Auto |
| Reducción de ruido digital | 3D DNR |
| WDR | DWDR |
| Clasificación resistente a la intemperie | IP67 |
| Distancia de Infrarrojo | 30m |
| Ángulo de visión | 2.8mm: 88.2°/48.7°/106.5°(H/V/D)4mm: 74.6°/41.3°/88.1°(H/V/D) |
| LENTES | |
|---|---|
| Tipo | Fixed Focal Lens |
| Longitud Focal | 2.8 mm/4 mm |
| Apertura | 2.8 mm: F2.24 mm: F2.0 |
| FOV | • 2.8 mm:Horizontal FOV:88.2°, Vertical FOV: 48.7°, Diagonal FOV: 106.5°• 4 mm:Horizontal FOV: 74.6°, Vertical FOV: 41.3°, Diagonal FOV: 88.1° |
| Montura del lente | M12 |
| Distancia DORI | • 2.8 mm:Detect: 45 m (149 ft)Observe:19 m (62 ft)Recognize: 9 m (30 ft)Identify: 5 m (15 ft)• 4 mm:Detect: 60 m (198 ft)Observe: 25 m (83 ft)Recognize: 12 m (40 ft)Identify: 6 m (20 ft) |
| Angle Adjustment (Manual) | |
|---|---|
| Range | • Pan: 0° to 355°• Tilt: 0° to 75° |
| ILLUMINATOR | |
|---|---|
| IR LED | • Quantity: 2• Range: 30m• Wavelength: 850nm |
| White LED | N/A |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
| VIDEO | |
|---|---|
| Max. Resolution | 1920 × 1080 |
| Main Stream | • Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution: 1920x1080, 1280x960, 1280x720• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Sub-Stream | • Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution: 704x576, 640x480, 352x288, 320x240• Note: If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Bit Rate Control | CBR, VBR |
| Compresión de Video | • Main Stream: H.265+/H.265/H.264+/H.264• Sub-Stream: H.265/H.264 |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | • Main Stream: 256 Kbps to 4 Mbps• Sub-Stream: 64 Kbps to 512 Kbps |
| Image | |
|---|---|
| Image Settings | • Mirror• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White Balance • Prevent Overexposure to Infrared Light• HLC Adjustable by Client Software• Rotation(90°/270°) |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | DWDR |
| SNR | ≥ 52 dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | Yes |
| AUDIO | |
|---|---|
| Comunicación de audio | N/A |
| Audio Input | Yes |
| Audio Output | N/A |
| Audio Compression | Yes |
| Audio Sampling Rate | 8KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64 Kbps(G.711 alaw) |
| NETWORK | |
|---|---|
| Protocolo | • TCP/IP• UDP• ICMP• HTTP• HTTPS• DHCP, DNS, RTSP• NTP• UPnP• SSL/TLS• FTP/SFTP• RTP• IPv4• ARP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S) |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, VIGI Security Manager, Web UI |
| Web Browser | • Google Chrome® 57 and above• Firefox® 52 and above• Safari® 11 and above• Microsoft® Edge 91 and above |
| Cloud | Yes |
| Seguridad | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| ALARMA Y GESTIÓN DE EVENTOS | |
|---|---|
| Smart Event | • Intrusion Detection• Line-Crossing Detection• Region Entering Detection• Region Exiting Detection• Object Abandoned/Removal Detection• Abnormal Sound Detection• People Detection• Vehicle Detection |
| Basic Event | • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)• Video Tampering Detection• Exception ( Illegal Login) |
| Alarm Linkage | Message Push |
| Linkage Method | N/A |
| Output Notification | Message Push |
| INTERFACES | |
|---|---|
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm | N/A |
| Reset Button | N/A |
| Power | N/A |
| Botón | - |
| Video Output | - |
| On-board Storage | N/A |
| Built-in Microphone | Yes; Records Anything Going on within a 15-ft Radius of the Camera |
| Built-in Speaker | N/A |
| Audio | N/A |
| GENERAL | |
|---|---|
| Temperatura de Funcionamiento | -30–60 °C |
| Storage Temperature | -40–60 °C |
| Humedad de funcionamiento | 95% or Less (Non-Condensing) |
| Storage Humidity | 95% or Less (Non-Condensing) |
| Contenidos del Paquete | • VIGI Network Camera• Quick Start Guide• Waterproof Cable Attachments• Mounting Accessories |
| Dimensions( H X W X D ) | 115 × 115 × 86 mm |
| Material | Plastic |
| General Features | Dos flujos, espejo, máscaras de privacidad, restablecimiento de contraseña por correo electrónico, escucha HTTP |
| Net Weight | 0.27 Kg |
| Gross Weight | 0.45 Kg |
| Power Consumption | PoE: Clase 0 |
| Power Supply | PoE: 802.3af/at, class 0, Max. 5.5 W |
| Vandal Resistant | IK10 |
| Protection | IP67 Waterproof, IK10 Vandal Proof |
| Product Dimensions (L x W x H) | 115× 115× 86 mm (4.53× 4.53× 3.39 in) |
| Certificaciones | CE, NTRA, VCCI, BSMI |
| VIDEO/IMAGEN | |
|---|---|
| Compresión de Video | Flujo principal: H.265+/H.265/H.264+/H.264 Flujo secundario: H.265/H.264 |
| Frame Rate & Resolutions | Flujo principal: Velocidad de fotogramas: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolución: 1920x1080, 1280x960, 1280x720 Sub-Stream: Frecuencia de imagen: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolución: 704x576, 640x480, 352x288, 320x240 |
| Max. Resolution | 2MP (1920 × 1080) |
| Video Streaming | Flujo principal Flujo secundario |
| Configuraciones de Imagen | Espejo, Brillo, Contraste, Saturación, Nitidez, Exposición, WDR, Balance de blancos Ajustable por Software Cliente, Rotación(90°/270°) |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Video Bit Rate | 64 Kbps a 4 Mbps |
| Day/Night Switch | Día/Noche/Auto/Programado |
| SMART FEATURE-SET | |
|---|---|
| Smart Event | Clasificación de personas y vehículos, Detección de intrusiones, Detección de cruce de líneas, Detección de personas, Detección de vehículos, Detección de entrada de regiones, Detección de salida de regiones, Detección de objetos abandonados, Detección de retirada de objetos |
| Basic Event | Detección de movimiento, Detección de manipulación de la cámara, Excepción (inicio de sesión ilegal) |
| Linkage Method | Notificación de activación: ONVIF, HTTPS |
| Region of Interest | 1 Región |
*Calculations based on laboratory testing using a 3MP VIGI camera, and an actual performance may vary according to the amount of activity recorded, resolution and other variables.
