Archer D7b
End of LifeAC1750 Wireless Dual Band Gigabit ADSL2+ Modem Router (Annex B)
- Supports 802.11ac standard - the next generation of Wi-Fi
- Simultaneous 2.4GHz 450Mbps and 5GHz 1300Mbps connections provide a premium wireless experience
- Share a printer locally and files & media with networked devices or remotely via FTP server.
- Ethernet WAN (EWAN) offers another broadband connectivity option for connecting VDSL, cable or fiber modems
Superfast Wireless Speed with 802.11ac
Coming with the next generation Wi-Fi standard – 802.11ac,
3 times faster than wireless N speeds, Archer D7b delivers a combined wireless data transfer rate of up to 1750Mbps with 1300Mbps over 5GHz and 450Mbps over 2.4GHz. 802.11ac also brings higher power efficiency and robust security, making Archer D7b a perfect hub for your home or small office network.
3 times faster than wireless N speeds, Archer D7b delivers a combined wireless data transfer rate of up to 1750Mbps with 1300Mbps over 5GHz and 450Mbps over 2.4GHz. 802.11ac also brings higher power efficiency and robust security, making Archer D7b a perfect hub for your home or small office network.
5GHz
2.4GHz
802.11n802.11ac
Premium Wireless Network Experience
Simultaneous dual band offers the flexibility of two dedicated networks for basic tasks and bandwidth-intensive applications respectively. 3 dual band detachable external antennas and high power amplifiers deliver ultimate range and performance.
Full Gigabit Wired Connection
With one Gigabit LAN/WAN port and 3 Gigabit LAN ports, the Archer D7b is the ideal choice for bandwidth-heavy users that rely on speedy, reliable connections for bandwidth-demanding work or entertainment such as lag-free conference calls, HD video streaming or online gaming.
Easy USB Storage and Sharing
Using the Archer D7b's two multi-functional USB 2.0 ports, you can share a printer with multiple comput-ers and devices on your network and can also share files & media at home or via the FTP server while away from home.
Interchangeable LAN/WAN Port
The Archer D7b supports ADSL or Ethernet WAN connections (EWAN),
which allows users to have the flexibility of different Internet connections
among ADSL, cable or fiber modem using its interchangeable LAN/WAN port.
This unique feature makes it easier when users need to
change to fiber or cable services when necessary.
which allows users to have the flexibility of different Internet connections
among ADSL, cable or fiber modem using its interchangeable LAN/WAN port.
This unique feature makes it easier when users need to
change to fiber or cable services when necessary.
Guest Network Access pro-
vides another secure Wi-Fi
access for guests sharing
your home or small office network
vides another secure Wi-Fi
access for guests sharing
your home or small office network
Parental Controls allow
parents or administrators to
establish restricted access
policies for children or staff
parents or administrators to
establish restricted access
policies for children or staff
Optimized configuration utility and
intelligent auto-detection which
automatically figures out connection
type help easily get online in a flash
intelligent auto-detection which
automatically figures out connection
type help easily get online in a flash
The Archer D7b supports IPv6,
the next generation of
Internet protocol, helping you
to future-proof your network
the next generation of
Internet protocol, helping you
to future-proof your network
Simple, Elegant, Modern
Inspired by modern architectural style and a well
suited gentleman, Archer D7b's exterior design
delivers a conception of simplicity and elegance,
and with gentle curves and fine crafting to
emanate quality.
plays a supporting role in the structure of the
shell body and achieves better cooling, while
also reflects the front LED indicators to look like
a continuation of itself.
suited gentleman, Archer D7b's exterior design
delivers a conception of simplicity and elegance,
and with gentle curves and fine crafting to
emanate quality.
The metal frame from the middle of the housing
plays a supporting role in the structure of the
shell body and achieves better cooling, while
also reflects the front LED indicators to look like
a continuation of itself.
The introduction on the lower right corner of the
metal TP-LINK Logo provides the whole design with
more texture and a better out-of-the-box experience.
metal TP-LINK Logo provides the whole design with
more texture and a better out-of-the-box experience.
Watch the Archer D7b video
TP-LINK | Wireless ADSL2+ Modem Routers
| Archer D7b | Archer D5 | TD-W8980 | TD-W8970 | TD-W8960N | |
| Products | AC1750 Wireless Dual Band Gigabit ADSL2+ Modem Router (Annex B) |
AC1350 Wireless Dual Band Gigabit ADSL2+ Modem Router |
N600 Wireless Dual Band Gigabit ADSL2+ Modem Router |
300Mbps Wireless N Gigabit ADSL2+ Modem Router |
300Mbps Wireless N ADSL2+ Modem Router |
| Standards | IEEE 802.11ac/ n/g/b/a |
IEEE802.11ac/ n/g/b/a |
IEEE 802.11n/ g/b/a |
IEEE 802.11n/ g/b |
IEEE 802.11n/ g/b |
| Wireless Speed | 1300Mbps 450Mbps |
867Mbps 450Mbps |
300Mbps 300Mbps |
300Mbps | 300Mbps |
| Wireless Range | |||||
| EWAN | √ | √ | √ | √ | √ |
| Gigabit Ports | √ | √ | √ | √ | - |
| USB 2.0 Ports | 2 | 2 | 2 | 2 | - |
| IPv6 | √ | √ | √ | √ | √ |
| HARDWARE FEATURES | |
|---|---|
| Interface | 1 10/100/1000Mbps RJ45 WAN/LAN Port 3 10/100/1000Mbps RJ45 LAN Ports 1 RJ11 Port 2 USB 2.0 Ports |
| Button | 1 Power On/Off Button 1 Wi-Fi On/Off Button 1 WPS Button 1 RESET Button |
| Power Supply | 12VDC/2.5A |
| IEEE Standards | IEEE 802.3, 802.3u, 802.3ab |
| ADSL Standards | Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite) ITU-T G.994.1 (G.hs), ITU-T G.995.1 |
| ADSL2 Standards | ITU-T G.992.3 (G.DMT.bis), ITU-T G.992.4 (G.lite.bis) |
| ADSL2+ Standards | ITU-T G.992.5 |
| Dimensions ( W x D x H ) | 9.0 x 6.3 x 1.5 in. (229 x 160 x 37mm) |
| Antenna Type | Three detachable dual band external antennas |
| Antenna Gain | 3 × 2dBi for 2.4GHz and 3 × 3dBi for 5GHz |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | IEEE 802.11ac/n/a 5GHz IEEE 802.11n/g/b 2.4GHz |
| Wireless Speeds | 5GHz: Up to 1300Mbps 2.4GHz: Up to 450Mbps |
| Frequency | 2.4GHz and 5GHz |
| Transmit Power | <20dBm(EIRP) |
| Wireless Functions | Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
| Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryption, Wireless MAC Filtering |
| Wireless Schedule | Support 2.4GHz and 5GHz Wireless Schedule |
| SOFTWARE FEATURES | |
|---|---|
| Quality of Service | ATM QoS, Bandwidth Control |
| Security | NAT Firewall, Access Control, MAC / IP / URL Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death IP and MAC Address Binding |
| IPv6 | IPv6 and IPv4 dual stack |
| Operating Modes | ADSL Modem Router, Wireless Router |
| Management | Web Based Configuration(HTTP), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools |
| DHCP | Server, Client, DHCP Client List, Address Reservation, DHCP relay |
| Port Forwarding | Virtual server, Port Triggering, DMZ, ALG, UPnP |
| Dynamic DNS | DynDns, NO-IP |
| VPN Pass-Through | PPTP, L2TP, IPSec Passthrough |
| ATM/PPP Protocols | ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed) Bridge (RFC1483 Bridge) PVC – Up to 8 PVCs |
| Advanced Functions | Parental Control Network Address Translation (NAT); Port Mapping (Grouping), Static Routing, RIP v1/v2 (optional); DNS Relay, DDNS, IGMP V1/V2/V3 |
| USB Sharing | Support Samba(Storage)/FTP Server/Media Server/Printer Server |
| Guest Network | 2.4GHz guest network × 1 5GHz guest network × 1 |
| IPSec VPN | Supports up to 10 IPSec VPN tunnels |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RCM, RoHS |
| Package Contents | AC1750 Wireless Dual Band Gigabit ADSL2+ Modem Router (Annex B) External Splitter RJ-11 Telephone Cable RJ-45 Ethernet Cable Quick Installation Guide Resource CD Power Adapter |
| System Requirements | Windows 10/8/7/Vista/XP or Mac OS or Linux-based operating system |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
† Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Range, coverage, and the maximum number of connected devices are based on test results under normal usage conditions. Actual wireless data throughput, wireless coverage, and number of connected devices are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.
