InSight S485PI
Sắp ra mắtVIGI 8MP IR Panoramic Turret Network Camera
- 180° Panorama View with Huge Vision
- 4K (8MP) Ultra HD and IR Range Up to 65.62 ft (20 m)*1
- Red-Blue Warning Lights with Stronger Deterrence
- People & Vehicle Analytics*2
- Human & Vehicle Classification
- Smart Detection
- Smart Video Enhancement Technology
- Audio and Alarm Interface Available
- IP67 Weatherproof and IK10 Vandal Proof
- H.265+ Compression Technology
Cut Project Costs with 180° View and 4K (8MP) Clarity
-
Normal View
-
Panoramic View
General cameras require multiple units to cover blind spots in large spaces like hotel lobbies, playgrounds, intersections, and warehouses, raising costs. A single panoramic camera with 180° view and 4K resolution reduces installation, deployment, and maintenance costs while covering more area.
General Camera
Panoramic Camera
Powerful, Efficient Monitoring with Active Defense
Active Defense is a monitoring feature that uses deep learning algorithms or external alarm devices to trigger flashing lights and loud sounds in real time, deterring intruders. It also supports user-created custom voice audio.
Red-Blue Warning Lights with
Stronger Deterrence
Red-blue flashing lights are more effective than white lights and create a strong deterrent effect when paired with audio alarms.
Flexible Audio & Alarm Integration
The Audio In/Out and Alarm In/Out ports enable easy integration with external alarm or access control devices.
(e.g.speaker)
(e.g.Acoustic Pickup)
(e.g. buzzer)
(e.g.sensor)
Instant Event Notifications
When the AI function detects an event or an external alarm device senses an event and sends a signal to the IPC, the alarm will trigger with alerts instantly sent to your phone.*3
VIGI AI Detection Technology
-
People & Vehicle Analytics: Search and filter to people or vehicle of interest based on many different attributes, like hair length, upper body color, vehicle type, making post-event search faster and easier.*2
-
Human & Vehicle Classification: Distinguish humans and vehicles from other objects, such as moving animals, falling leaves, changing lights, and receive more accurate event notifications.
Smart Video Enhancement Technology
-
True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
-
Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
-
3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
-
White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.*4
| CAMERA | |
|---|---|
| Cảm biến hình ảnh | 1/2.7“ Progressive Scan CMOS |
| Tốc độ màn trập | 1/3 to 1/10000 s |
| Phơi sáng | Yes |
| Nhạy sáng tối thiểu | 0.005 Lux; 0 Lux with IR light |
| Cơ chế Ngày/Đêm | IR Cut Filter |
| Chuyển đổi Ngày/Đêm | Unified/ Scheduled/ Auto |
| Ống kính | |
|---|---|
| Loại | Fixed Focal Lens |
| Độ dài tiêu cự | 1.65 mm |
| Khẩu độ | F2.0 |
| FOV | 1.65mm:• Horizontal FOV: 180°• Vertical FOV: 86°• Diagonal FOV: 180° |
| Ngàm ống kính | M12 |
| Khoảng cách DORI | 1.65mm• Detect: 144.36 ft (44 m)• Observe: 60.15 ft (18.33 m)• Recognize: 28.87 ft (8.8 m)• Identify: 14.44 ft (4.4 m) |
| Điều chỉnh góc (Thủ công) | |
|---|---|
| Vùng | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| Đèn chiếu sáng | |
|---|---|
| Đèn hồng ngoại IR | Quantity: 4Range: 65.62 ft (20 m)Wavelength: 850 nm |
| Điều khiển bật/tắt đèn chiếu sáng | Auto/Scheduled/Always on/Always off |
| VIDEO | |
|---|---|
| Độ phân giải tối đa | 3840x2160 |
| Luồng chính | • Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:3840x2160,2560x1440,2304x1296,2048x1280,1920x1080,1280x720Note:• If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Luồng phụ | • Frame Rate：50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps• Resolution:848x480,704x576, 640x480, 640x360,352x288, 320x240• Note:If the image rotation is set to 90° or 270°, the frame rate only supports up to 20fps. |
| Kiểm soát Bit Rate | CBR, VBR |
| Nén video | Main Stream: H.265+/H.265/H.264+/H.264Sub-Stream: H.265/H.264 |
| Loại H.264 | High Profile |
| H.264+ | Main Stream Supported |
| Loại H.265 | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | Main Stream: 256 Kbps to 8 MbpsSub-Stream: 64 Kbps to 1024 Kbps |
| Hình ảnh | |
|---|---|
| Cài đặt hình ảnh | • Mirror• Brightness• Contrast• Saturation• Sharpness• Exposure• WDR• White Balance• Prevent Overexposure to Infrared Light• HLC Adjustable by Client Software |
| Tăng cường hình ảnh | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | 120 dB |
| SNR | ≥ 52 dB |
| Chuyển đổi thông số hình ảnh | Yes |
| Vùng riêng tư | Up to 4 Masks |
| ROI | 4 Region |
| Cài đặt OSD | Yes |
| Âm thanh | |
|---|---|
| Đàm thoại | Two-Way Audio |
| Âm thanh vào | Built-in MicrophoneAudio In Interface |
| Âm thanh ra | Built-in SpeakerAudio Out Interface |
| Nén âm thanh | Yes |
| Sampling Rate âm thanh | 8 KHz |
| Lọc tiếng ồn môi trường | Yes |
| Bit Rate âm thanh | 64 Kbps(G.711 alaw) |
| MẠNG | |
|---|---|
| Giao thức | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S/T/G) |
| Xem trực tiếp đồng thời | 3 Main Streams & 3 Sub-Streams |
| Kết nối và điều khiển | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS |
| Trình duyệt Web | Google Chrome® 57 and aboveFirefox® 52 and aboveSafari® 11 and aboveMicrosoft® Edge 91 and above |
| Cloud | Yes |
| Bảo mật | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| QUẢN LÝ SỰ KIỆN VÀ BÁO ĐỘNG | |
|---|---|
| Sự kiện thông minh | • Intrusion Detection• Line-Crossing Detection• Region Entering Detection• Region Exiting Detection• Object Abandoned Detection• Object Removal Detection• Loitering Detection• People Detection• Vehicle Detection• Abnormal Sound Detection• Scene Change Detection |
| Basic Event | • Motion Detection (Enhanced with Human & Vehicle Classification for more accurate alerts)• Video Tampering Detection• Exception ( Illegal Login)• Alarm Input Device |
| Alarm Linkage | • Memory Card Video Recording• Upload to FTP Server• Alarm Output Device• Push Notifications• Send to Alarm Server• Active Defence-Sound Alarm• Active Defence-Light Alarm• Email Alarm |
| Deep Learning Function | |
|---|---|
| People & Vehicle Analytics | Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.3 |
| Giao diện kết nối | |
|---|---|
| Kết nối mạng | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Báo động | 1 Alarm In, 1 Alarm OutRed-Blue Warning Lights |
| Nút Reset | Yes |
| Nguồn | DC Power Port |
| Lưu trữ trên thiết bị | Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB*5 |
| Micro tích hợp | Yes; Records Anything Going on within a 15-ft Radius of the Camera |
| Loa tích hợp | Yes |
| Âm thanh | 1 Audio In, 1 Audio Out |
| THÔNG TIN CHUNG | |
|---|---|
| Nhiệt Độ Hoạt Động | -30 to 60 °C |
| Storage Temperature | -40 °C to 60 °C |
| Độ Ẩm Hoạt Động | 95% or Less (Non-condensing) |
| Storage Humidity | 95% or Less (Non-condensing) |
| Sản phẩm bao gồm | VIGI Network CameraQuick Start GuideWaterproof Cable AttachmentsMounting Accessories |
| Chất liệu | Metal |
| Khối lượng tịnh | 0.76 Kg |
| Power Supply | • 12V DC ± 5%, Max. 18 W, 5.5 mm Coaxial Power Plug• PoE: 802.3at, class 4, Max. 21 W |
| Protection | IP67 Waterproof, IK10 Vandal Proof |
| Product Dimensions (L x W x H) | 4.4 × 4.4 × 4.3 in (112.3 × 112.3 × 110.2 mm) |
| Chứng Chỉ | CE, NTRA, KC, FCC, VCCI, BSMI, ONVIF, IP67, IK10 |
*1 Calculations are based on laboratory testing. Actual data is not guaranteed and will vary as a result of client limitations and environmental factors.
*2 This feature is in development and will update with future software iterations, and it must be used with VIGI specified software.
*3 AI-trigger notification supports playback of specific event clips, notifications triggered by external alarm devices only support live view.
*4 Calculations based on laboratory testing using a 3MP VIGI camera, and an actual performance may vary according to the amount of activity recorded, resolution and other variables.
*5 The microSD card and pole mounting kits are not included in the package.
